This unit consists of:
- A classical venturi test section made of clear acrylic for flow visualization
- A pitot static tube that can be traversed across the centerline of the venturi section
- A manometer bank with eight tubes for measuring the static pressure distribution along the converging test section and total pressure traversed along the centerline of the test section.
- Demonstration of venturi as a flow measurement device
- Determination of the venturi discharge coefficient
